What is GIS?

GIS stands for: Geographic Information System

It is a computer system for capturing, storing, checking, and displaying data related to positions on Earth’s surface.

• This is a terrific resource: National Geopgraphic - GIS
• This is another: ESRI - What is GIS?

What is a CRS?

CRS stands for: Coordinate Reference System

A coordinate reference system, or CRS, is how spatial data that represent the earth’s round AND 3-Dimensional surface are flattened onto a 2 dimensional surface (think of squishing half of a tennis ball flat so that it could be represented on a piece of paper).

There are Geographic Coordinate Systems which have angular units and are developed from a spheroid representation of the Earth, and a prime meridian for reference. There are also projected coordinate systems which have linear units (e.g. feet or meters).

Go through this tutorial to get a better understanding of coordinate reference systems

• Earth data science

The components of a CRS are:

1. Coordinate system

• Source: What is a coordinate system?

2. Units of the datum (horizontal and vertical)

A geographic coordinate system, such as the one on the left below, has angular units and defines locations on a sphere. A projected coordinate sytem is flat, and has linear units. If your spatial analysis requires calculating distances in meters, you will want to set your Coordinate Reference System to one that uses meters. UTM stands for Universal Transverse Mercator and is one of the main CRS’s you will encounter. UTM contains a series of small projections that minimize the distortion you might see if you use latitude and longitude.

• Source: ESRI
• Differences in coordinate systems


3. The Datum

Geographic information system datum define the position of the spheroid relative to the center of the earth.

• Source: Why we need datums

4. Projection information

Again, the projection is a representation of a round surface (the Earth) onto a 2-dimensional flat surface (a map). This involves algorithms that transform each of the Earth’s graticules (lines on the earth, latitude and longitude) onto a flat surface. The projection information documents how this was done and what the units of the outcome are.

• This is a great source for CRS IDs
• And another resource on Using projections in R

Rasters

Rasters are continuous data, think of color spectra or the range of moods you may have from very angry to quite happy. You are rarely just one of these and there are infinite gradations depending on how irksome other drivers are or if you got the perfect birthday cupcake.

Rasters come from technologies such as aerial photography and remote sensing imagery. The colors or variations in the cells reflect information like air pollution concentrations or tree canopy cover.

Rasters are stored in a matrix of cells, like a table and the size of the cell represents the resolution of the information. If the cell is 50m x 50m, then there will be no additional information variation within that size of a cell. If the raster was showing temperature, then their will be a single temperature value for that entire. The smaller the cell size, the greater or finer the resolution of the data.

• Source: What is raster data?

Spatial analysis with R

A powerful tool in R for spatial analysis and geospatial data is the sf package.

Reading in data

The main type of data you will be reading in are shapefiles. Shapefiles are not one file, but are actually a set of files that include the data, the projection, the coordinates, and information that tells the software the type of data it is.

The other main type of data you will experience is a flat table of data with X/Y coordinates, like longitude and latitude. This is the type of data we will work with today, but once we set it up as a spatial data set we will save it as a shapefile.

Let’s pull in some point data. Each point in this dataset represents a specific tree planted along a street in San Francisco.

The curious can see more about this dataset at San Francisco Trees.

# Only need to run this once
install.packages("sf")

library(sf)
library(tidyverse)

url <- "https://tidy-mn.github.io/R-camp-penguins/data/sf_trees.csv"

sf_trees <- read_csv(url)

Now, let’s look at the data.

View(sf_trees)

class(sf_trees)

The dataframe has latitude and longitude columns containing each point’s coordinates, but R does not yet know that this is a geographic data set.

When we begin with a CSV file of coordinates, we must tell R to convert it to a spatial dataset. This will add a new geometry column to the dataframe that will be used for mapping the data.

# Error!
sf_trees_geo <- st_as_sf(sf_trees,
                         coords = c("longitude", "latitude"),
                         crs = 4269,
                         remove = FALSE)

## Error in st_as_sf.data.frame(sf_trees, coords = c("longitude", "latitude"), : missing values in coordinates not allowed

Drats! R is right again. There are some missing coordinates or NA’s in the latitude and longitude columns. If we attempt to convert the missing data to a geometry we will get an error for missing coordinates.

We need to get rid of the trees or rows in the data with missing coordinates. Here are two ways.

# With filter() and !is.na()
sf_trees <- filter(sf_trees, !is.na(longitude), !is.na(latitude))

# Alternative: drop_na()
## If NA appears in *either* of the columns you provide, the row will be dropped
sf_trees <- drop_na(sf_trees, longitude, latitude)

Now that we have filtered out the missing latitude and longitude values, we can run st_as_sf() without an error. This function requires the data, the name of the columns that contain the coordinates, and the data’s current coordinate reference system.

If you include the argument, remove = FALSE, the latitude and longitude columns will be retained in addtion to adding a geometry column. Otherwise they will be removed as they are combined into the geometry column.

sf_trees_geo <- st_as_sf(sf_trees,
                         coords = c("longitude", "latitude"),
                         crs = 4269,
                         remove = FALSE)

To check this worked properly, try making a simple plot of the data using the base R function plot(). To start with, we will only map the first column. This is simply to make the plotting faster. Feel free to try plotting all of the attributes and see what happens.

Heads up, this may take a few minutes for large datasets like this one.

It will be difficult to see what is going on here, since at least one tree is very far away from the rest of the trees. Apparently out in the middle of the ocean. Perhaps it is growing on a ship?

# Show a single layer
plot(sf_trees_geo[1])

# Show all the layers
plot(sf_trees_geo)

Not too impressive, is it?.

Since we are only interested in the trees within the City of San Francisco boundaries, let’s look at which trees overlap or intersect with the City of San Francisco limits.

We first need to read in a city spatial dataset. Then we will filter it to only include San Francisco. Finally, we will run the intersection (within) function on the trees.

library(tigris)

options(tigris_use_cache = TRUE)

cities <- metro_divisions()

san_fran <- filter(cities, str_detect(NAME, "San Francisco"))

plot(san_fran[1])

st_crs(san_fran)

st_crs(sf_trees_geo)

trees_in_san_fran <- st_intersection(sf_trees_geo, san_fran)

# Plots a single layer
plot(trees_in_san_fran[1])

Saving maps: st_write( )

Since we are very interested in these trees and know we’ll use the data later, let’s save this new spatial data set with st_write().

The first argument in st_write() is the name of the data in R we are saving, and the second argument is the file location and name to save to. The .shp file ending saves the data as a spatial shapefile. This is a common GIS file format for ESRI users and consists of several files.

The main files have the following extensions:

• .prj: The detailed projection information, such as Lat/Long or UTM
• .dbf: The attribute data, or the columns of data in our dataframe
• .shp: The shape information, or the geometry column in our dataframe

Another common spatial format is .geojson, which has the advantage of only being a single file. This makes it easier to share with others and will generally save a bit of storage space.

Finally, we include delete_layer = TRUE to the st_write funciton to say it’s okay to save over previous versions of the file if it already exist in the folder we are saving to.

# Save as a shapefile (multiple files, good for ESRI/ArcGIS)
st_write(trees_in_san_fran,
         "trees_in_san_fran.shp",
         delete_layer = TRUE)

# Save as geojson (single file, good for sharing)
st_write(trees_in_san_fran,
         "trees_in_san_fran.geojson",
         delete_layer = TRUE)

Buffers: Go beyond the point

Let’s draw a buffer around each tree in our filtered data set. In your work you may need to draw buffers around point data either when locations are uncertain to a specific level of precision, or if you want to find how many people live within 5 miles of a school or hospital.

To draw a buffer we must make sure the coordinates are linear rather than angular. Remember when we talked about coordinate reference systems? Lat/long uses angular coordinates and is not so great for calculating distances between points or for calculating areas of polygons. The Universal Transverse Mercator or UTM system on the other hand has coordinates in meters and is a better fit for calculating surface distances.

Let’s transform the tree coordinates from lat/long to UTM.

San Francisco is in UTM Zone 10: CRS = 32610.

# Convert CRS from Lat/Long to UTM zone 10 (San Francisco)
trees_in_san_fran <- st_transform(trees_in_san_fran, crs = 32610)

# Add a 1,000 meter (1 KM) buffer around each tree
trees_in_san_fran <- st_buffer(trees_in_san_fran, dist = 1000)

# View the new plot, w/ BIG overlapping circles
plot(trees_in_san_fran[1])

Going the distance

As a next step, we will calculate the distances between the trees and another location of interest. Let’s find which tree is closest to a specific loon floating on Leech Lake all the way over in Minnesota. You know… as one does.

Below, we create a dataset with a single point using the coordinates stored as latitude and longitude. This is our special loon!

# Our very exact loon coordinates in MN
loon_lat <- 47.1505

loon_long <- -94.3839

# Add the coords to a dataframe
loon_coords <- data.frame(lake = "Leech Lake",
                          lon = loon_long,
                          lat = loon_lat)

loon_mn <- st_as_sf(loon_coords,
                    coords = c("lon", "lat"),
                    crs = 4269)

loon_mn <- st_transform(loon_mn, crs = "ESRI:102003")

trees_in_san_fran <- st_transform(trees_in_san_fran, crs = "ESRI:102003")

Calculate the st_distance( )

We’ll use the st_distance() function to calculate the distance between each of the trees and our loon.

tree_distances <- trees_in_san_fran %>%
                  mutate(distance_to_loon_m = st_distance(geometry, loon_mn))

Let’s also add a column with the distance shown in kilometers by dividing the calculated distance by 1,000 meters.

The as.numeric() is added below to remove the meters units from the original distance value.

tree_distances <- tree_distances %>%
                  mutate(distance_to_loon_km = as.numeric(distance_to_loon_m) / 1000)

To determine the closest tree in San Francisco to our loon, let’s run min() on the column distance_to_leech_km, and use filter() to keep the only row where its distance is equal to the minimum distance.

closest_tree <- tree_distances %>%
                filter(distance_to_loon_km == min(distance_to_loon_km))

glimpse(closest_tree)

## Rows: 1
## Columns: 27
## $ tree_id             <dbl> 256051
## $ legal_status        <chr> "Undocumented"
## $ species             <chr> "Platanus x hispanica :: Sycamore: London Plane"
## $ address             <chr> "200 The Embarcadero"
## $ site_order          <dbl> 8
## $ site_info           <chr> "Sidewalk: Curb side : Cutout"
## $ caretaker           <chr> "DPW"
## $ date                <date> NA
## $ dbh                 <dbl> NA
## $ plot_size           <chr> "3x3"
## $ latitude            <dbl> 37.79167
## $ longitude           <dbl> -122.3904
## $ CSAFP               <chr> "488"
## $ CBSAFP              <chr> "41860"
## $ METDIVFP            <chr> "41884"
## $ GEOID               <chr> "4186041884"
## $ NAME                <chr> "San Francisco-San Mateo-Redwood City, CA"
## $ NAMELSAD            <chr> "San Francisco-San Mateo-Redwood City, CA Metro Di…
## $ LSAD                <chr> "M3"
## $ MTFCC               <chr> "G3120"
## $ ALAND               <dbl> 1283429131
## $ AWATER              <dbl> 1236270696
## $ INTPTLAT            <chr> "+37.5126658"
## $ INTPTLON            <chr> "-122.4361768"
## $ geometry            <POINT [m]> POINT (-2272486 350263.1)
## $ distance_to_loon_m  [m] <units[1 x 1]>
## $ distance_to_loon_km <dbl> 2503.948

That’s our tree! Number 256051. The wonderful bark shedding Platanus x hispanica, also known as the London plane tree. And good news, it is only ~2,500 kilometers away.

Pssst… for the extra curious bees in the room. Here is where the tree is in San Francisco. It looks to be planted along The Embarcadero near little Rincon Park.

# Only need to run this once
install.packages("leaflet")

library(leaflet)

# Transform the closest tree back to Lat/Long coordinates
closest_tree <- st_transform(closest_tree, crs = 4326)

# Add it to a leaflet map along with ALL the trees
leaflet(trees_in_san_fran) %>%
  addTiles() %>%
  addCircles(lat = ~latitude,
             lng = ~longitude,
             color = "darkgreen") %>%
  addMarkers(data = closest_tree,
             lat = ~latitude,
             lng = ~longitude)
